11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
67
GPTWR ELECTRICAL VALUES
SYSTEM DIAGRAMS
Solenoid Switch
12V 24V
Coil Resistance:
5.4Ω @70ºF. ±15% 20.1Ω @70ºF. ±15%
Ampere:
2.2A 1.2A
Coil terminal torque: 10-15 lb-in max.
Contact terminal torque: 30-35 lb-in max.
Solenoid Valves (A, S1, & S2)
Coil Resistance:
4.0Ω @ 70ºF. ±15% 26.7Ω @ 70ºF. ±15%
Ampere:
3A, 2.5A @10V
Coil terminal torque: 15-45 lb-in max.
Valve cartridge torque: 25-30 lb-ft max.
Coil nut torque: 15-45 lb-in
Solenoid Lock Valve
Coil Resistance:
8.0Ω @ 70ºF. ±15% 30Ω @ 70ºF. ±15%
Ampere:
1.5A 0.8A
Coil terminal torque: 3-4.5 lb-ft max.
Valve cartridge torque: 18.5-22 lb-ft max.
Ground Cable
Cap Screw Torque: 24 lb-ft max.
TABLE 67-1
