STANDARD LIFTGATE COMPONENTS
CAUTION
!
NOTE: Make sure you have all components and parts before you start installing Liftgate.
Compare parts in the part box and each kit box with packing list enclosed in each
box. If parts and components are missing or incorrect, call:
Maxon Customer Service
Call (800) 227-4116 or
Send e-mail to cservice@maxonlift.com
Unpacking the Liftgate on unlevel surface may allow heavy components to slide off
when shipping bands are cut. Injury and equipment damage could result. Before
the shipping bands are cut, put Liftgate on level surface that will support 1500 lbs.
When unpacking the Liftgate, remove heavy components carefully to avoid injury
and damage.
EXTENSION PLATE
MAIN
ASSEMBLY
PARTS
BOXES
OPENER
STEP KIT
ASSEMBLY
(DUAL STEPS
SHOWN)
TYPICAL LIFTGATE COMPONENTS FOR SHIPMENT
(OPTIONAL COMPONENTS NOT SHOWN)
FIG. 7-1
