GPTWR INSTALLATION PARTS BOX
PARTS BOX A WITH POWER CABLE
TABLE 8-1
PARTS BOX C WITH GROUND CABLE
TABLE 8-3
PARTS BOX B WITHOUT POWER CABLE, GROUND CABLE, OR FRAME CLIPS
TABLE 8-2
ITEM NOMENCLATURE OR DESCRIPTION QTY. PART NUMBER
REF PARTS BOX A 1 297502-01
1 SPRING CLIP, 1/2” x 1-3/8” 10 050079
2 PLASTIC TIE 2 206864
3 #10 RUBBER LOOM CLAMP 2 801681
4 CABLE ASSEMBLY, 175 AMPS, 38 FT LG. 1 264422
5
SELF-TAPPING SCREW, 10 X 1/2” LG. 2 030458
6
GROUND CABLE ASSEMBLY, 2 GA X 48” LG. 1 251871-26
ITEM NOMENCLATURE OR DESCRIPTION QTY. PART NUMBER
REF PARTS BOX C 1 297502-02
1 SPRING CLIP 20 050079
2 PLASTIC TIE 4 206864
3 GROMMET, 1” DIA, 2 HOLES 1 266428-09
4 CABLE ASSY, 175 AMP 38 FT LG 1 264422
5 GROUND CABLE ASSY, 2 GA X 38FT LG 1 269191-01
6 #10 LOOM CLAMP 2 801681
7
SELF-TAPPING SCREW, 10 X 1/2” LG. 2 030458
ITEM NOMENCLATURE OR DESCRIPTION QTY. PART NUMBER
REF PARTS BOX B 1
297049-02
1 SHIM, 2-1/2” X 1” X 16 GAUGE 2 264732
2 TOGGLE SWITCH ASSEMBLY 1 296855-01
3 FLAT WASHER, 1/2” X 5/16” THICK 2 902000-13
4 HEX NUT, 1/2”-13 2 901011-9
5 CAP SCREW, 1/2’’-13 X 1-1/2” LG. 2 900035-3
6 INSTALLATION BRACKET 2 269462-01
7 LUG, 2 GAUGE, COPPER, 5/16” 1 906497-02
8 SCREW, SELF TAPPING, #10-24 X 1-1/2” LG 2 900057-7
9 HEAT SHRINK TUBING, 3/4” X 1-1/12” LG. 1 253316-04
10 FLAT, 2-1/2” X 1” X 1/8” THICK 2 201999
11 LICENSE PLATE BRACKET KIT 1 287015-01
To Next Page
