56
STEP 11 - BOLT PLATFORM OPENER TO LIFTGATE
- Continued
MODEL PLATFORM & FLIPOVER
BED
HEIGHT
HOLE ON
OPENER ARM
HOLE ON
BRACKET
TE-25/TE-30
(HIGH BED)
22”+14” STEEL & STEEL
44” TO 50” #1 B
50” TO 54” #2 A
22”+18” ALUM & ALUM
44” TO 54” #1
A
48” TO 52” #2
52” TO 54” #3
26”+26” STEEL & ALUM, OR ALUM & ALUM
42” TO 48” #1
A48” TO 52” #2
52” TO 54” #3
TE-15/TE-20
(HIGH BED)
22”+14” STEEL & STEEL
42” TO 50” #1 B
50” TO 54” #2 A
22”+18” ALUM & ALUM
42” TO 48” #1
A
48” TO 52” #2
52” TO 54” #3
TE-25L/TE-30L
(LOW BED)
22”+14” STEEL & STEEL
36” TO 44” #1 A
24”+24” STEEL & STEEL, OR ALUM & ALUM
TE-15L/TE-20L
(LOW BED)
22”+14” STEEL & STEEL
36” TO 44” #1 A
22”+18” ALUM & ALUM
PLATFORM OPENER & BRACKET MOUNTING HOLES
TABLE 56-1
