5.3.2.2 Playback Control
Playback control bar, as shown in picture 5-9.
Picture 5-9
Detailed brief description is shown as below list
Key
Stop playing all the playback
Record file clip
After opening playback, click icon to clip the selected file; and click again to stop
the clip function. Then playback clip is successfully done. Record clip file will be saved as
*.264 format.
Snapshot function
Move the mouse curse to the channel you want to capture, and click [ ] icon to capture
the live images remotely. After capturing the images successfully, a path prompt box will
be popped up, as shown in Picture 5-10.
Picture 5-10
The captured file will be saved as .bmp format.
Table 5-1
