MBO RW500 - Emissions; Shipping and Transport Data

44
Rewinder RW500
Product description
Technical data
3.2.4 Emissions
3.2.4.1 Noise emissions
3.2.5 Shipping and transport data
Noise emissions
Specified two-digit noise emissions value according to DIN EN 4871 Idling Load
A-weighted sound power level L
WA
in dB re 1 pW
Uncertainty K
WA
in dB
-
-
-
-
A-weighted emission sound pressure level L
PA
In dB re 20 Pa at the operating place
Uncertainty K
WA
in dB
-
2.5
< 70
2.5
The values were determined in accordance with the noise emission standard DIN EN ISO 13023
1)
using the basic standards DIN EN ISO 3746 and DIN EN ISO 11204
Table 15: Noise emissions
1) Noise measurement EN ISO 13023 F.1 - Class 2
Weight piece Net Gross
RW500
Production Approx.
2170 kg
Approx.
3020 kg
1)
Shipping pallet Approx.
2170 kg
Approx.
2470 kg
Shipping crate Approx.
2170 kg
Approx.
2750 kg
Dimensions
L x W x H
RW500
Without packaging 336x 160 x 145 (cm)
With transport pallet 350 x 180 x 200 (cm)
With shipping crate 355 x 185 x 210 (cm)
Fork lift
2)
Carrying capacity / load (Q)
3)
Min. 3000 kg
Fork tine length Min. 200 cm
Floor conditions
Cargo
4)
> 25 kN/m
2
Levelness
5)
< 10 mm/m
Table 16: Shipping and transport data
1) Total weight with a maximum load of 1200 kg.
2) Minimum requirements of the fork lift
3) Heed operating manual for the fork lift, load capacity depends on the load center of gravity (c).
4) Minimum load capacity of the floor where the machine will be set up
5) In the area of the machine, the total height difference may not exceed 20 mm.
