Rewinder RW500
Product description
Technical data
3.2.7 Compressed air supply, control air
3.2.8 Ambient conditions
Compressed air supply Minimum Maximum
Connected loads
Necessary network pres-
sure
6 bar 7 bar
Average consumption
1)
10 l/min
Purity class
2)
ISO 8573-1:2010 [3:4:2]
3)
Schott plug connection QSS-8
Connecting line
Hose with external diame-
ter
8mm
Table 18: Compressed air supply, control air
1) Required volume flow according to ISO 1217 or DIN 1945
2) Purity class according to ISO 8573-1:2010 [particles:water:oil].
3) Typical purity classes for the publishing and print sector (control air) in compliance with VDMA standard sheet
15390-1:2014-12, table 5.
Room temperature
17 ... 35 °C
1)
Storage temperature
10 ... 35 °C
Relative humidity
Optimal
Minimum
Maximum
40 - 60 %
30 %
80 % (non-condensing)
Set-up height
2)
Max. 1500 above sea level
Table 19: Ambient conditions
1) At temperatures below or above the permissible room temperature, special measures must be taken.
2) For installation at an altitude of 1000 m above sea level or higher, a power reduction of 1 % per 100 m should
be incorporated.
Avoid direct sunlight and drafts.
