Rewinder RW500
Operating and display elements, operating modes
Operating and display elements
8 <Raise/lower pressure arm> illuminated push button.
Can only be changed if <Setup> operating mode is active.
Press the illuminated button for approx. 3 seconds to raise/lower the
pressure arm.
Status indicator of the light ring:
Yellow = pressure arm is raised, <Setup/Threading> position.
Green = pressure arm is lowered, <Production> position.
9 <Production/setup dancer position> weight force danger illuminated
push button.
Only active in the <Setup> operating mode.
Status indicator of the light ring:
Off = <Production> operating mode is active.
Yellow = <Setup / Threading> dancer in position.
Green = <Production> dancer in position.
10 <Inch> illuminated push button of the in-feed shaft.
Status indicator of the light ring:
Off = inching off.
White = inching on
11 <Stop request> illuminated button
<Stop request> can only be carried out if the illuminated button lits red.
Status indicator of the light ring:
Off = <Production> operating mode is active, printer is inactive.
Red = <Production> operating mode is active, printer is active.
The following functions are automatically moved to the <Production> po-
sition after switching to the <Production> operating mode (3):
• Weight force dancer (9)
• Pneumatic dancer (4)
• Pressure arm (8)
