53
How to Assign the Tuner Presets
TUNER SETUP
The MHT100 Setup Mode Tuner Presets allow for the pre-
setting into memory 9 FM and 9 AM Radio Stations for
fast recall at any time. In addition, any preset can have a
unique name assigned to it. When the preset station is re-
called, the Front Panel Alphanumeric Display will show
the name instead of the station’s frequency.
Note: The Tuner Setup Mode is applicable only for the
internal Tuner Module.
1. Press and hold the Front Panel SETUP Push-button ap-
proximately three seconds to enter the Setup Mode.
The word SETUP will appear on the MHT100 Front
Panel Display and the MAIN SYSTEM SETUP Menu
will appear on the Monitor/TV screen. Refer to figure
63.
2. Using the Up or Down directional push-buttons
select Tuner Presets on the On-Screen Menu, followed
by the SELECT Push-button on the Remote Control.
Note: Follow the steps below for each Broadcast Station
Preset you wish to enter into memory.
3. Using the Up or Down directional push-buttons
select Number 1 PRESET from the On-Screen Menu,
followed by pressing the Left or Right directional
push-buttons to select the desired Preset. Refer to fig-
ure 64.
Note: The Presets will scroll through FM Preset 1 to 9 and
then to AM Presets 1 to 9.
Tuning Mode
The MHT100 allows for selection of Broadcast Stations
either by scrolling through the Presets that are stored in
memory or Tuning Manually. This setting is used for both
entering Presets and for actual operation using the Front
Panel TRIM/TUNE Up or Down directional push-but-
tons.
4. Using the Up or Down directional push-buttons
select Number 2 TUNE from the On-Screen Menu, fol-
lowed by pressing the Left or Right directional
push-buttons to select AUTOmatic (for selecting Preset
Stations) or MANUAL (for Manually Tuning Up or
Down the broadcast band, for selecting Stations).
Note: The PRESET TUNING MODE setting of AUTO or
MANUAL only needs to set for one of the 18 Presets,
as it is a global setting effecting
Frequency
5. Using the Up or Down directional push-buttons
select Number 3 FREQUENCY from the On-Screen
Menu, followed by pressing the Left or Right di-
rectional push-buttons to select the Frequency of the
Broadcast Station that you wish to enter into memory.
Refer to figure 65.
Figure 64
MENU: TUNER PRESETS
1. PRESET FM1
2. TUNING MODE Auto
3. FREQUENCY 87.50 MHz
4. LABEL PRESET1
5. PRESET ASSIGNED No
EXIT
Figure 63
MAIN SYSTEM SETUP
1. SPEAKER SIZE
2. SPEAKER TIME DELAY
3. SPEAKER LEVEL
4. SUBWOOFER SETTINGS
5. SOURCE SETTINGS
6. VIDEO POWER CONTROL
7. TUNER PRESETS
8. SYSTEM SETTINGS
EXIT
Note: FM Broadcast Band Indications are in Megahertz. In
the US and Canada the frequency changes are in
100kHz steps. The second digit to the right of the dot
which displays a 0, is used for FM stations in various
Figure 65
