54
TUNER SETUP, con’t
Figure 67
MENU: TUNER PRESETS
1. PRESET FM1
2. TUNING MODE Auto
3. FREQUENCY 91.50 MHz
4. LABEL Jazz-BA
5. PRESET ASSIGNED Yes
EXIT
locations other than the US where stations change in
50Hz steps. AM Broadcast Band Indications are in
Kilohertz and change frequency in 10kHz steps.
Label
6. Using Up or Down directional push-buttons select
Number 4 LABEL followed by pressing the SELECT
Push-button. The On-Screen Menu will now change,
allowing the current Label Name to be altered. Refer to
figure 66.
7. The On-Screen Display will show an arrow under-
neath the left most character of the current LABEL
Name. Press the Up or Down directional push-
buttons to select the desired character from the avail-
able characters that include the alphabet, numbers and
symbols.
8. To change the next character press the Rightu direc-
tional push-button to move the arrow to change the
next character. Press the Up or Down directional
push-buttons again to select the desired character.
9. Repeat step 6 until the desired Preset Label Name is
complete.
Note: The Input Title Name can be up to seven characters
long.
10. After the last character has been entered press the
Left or Right directional push-buttons (or press the
SELECT Push-button) until the TUNER PRESET
Menu displays number 5, PRESET ASSIGNED.
Preset Assigned
11. Using Up or Down directional push-buttons select
Number 5 PRESET ASSIGNED from the On-Screen
Menu, followed by pressing the Left or Right di-
rectional push-buttons to select Yes or No. If No is se-
lected the MHT100 will skip that Preset, even though it
has been entered. Refer to figure 67. Select EXIT on
the menu and the MAIN SYSTEM SETUP Menu will
reappear on the Monitor/TV screen.
12. Continue next to the SYSTEM SETUP on page 38 or if
you do not wish to perform SYSTEM SETUP Adjust-
ments at this time, proceed to the next step.
13. Continue next to the SYSTEM SETUP or you do not
wish to perform SYSTEM SETUP Adjustments at this
time, proceed to the next step.
14. Select EXIT from the MAIN SYSTEM SETUP Menu.
If you are satisfied with the changes that you may have
made, select YES to save those changes or NO not to
save them. The MHT100 will then return to normal op-
eration. Refer to figure 13 on page 25.
Figure 66
MENU: TUNER PRESETS
1. PRESET FM1
2. TUNING MODE Auto
3. FREQUENCY 91.50 MHz
4. LABEL JAZZ-BA
EXIT
