IM-738 Page 85
Check, Test and Start Procedure for RoofPak roof mounted air conditioners with or without heat recovery; roof mounted air handlers
and SuperPak roof mounted supermarket units.
Job Name:_______________________________________________________ McQuay G.O. No.: _________________________
Installation Address: ________________________________________________________________________________________
City: ____________________________________________________________________________State:____________________
Purchasing Contractor: ______________________________________________________________________________________
City: _____________________________________________________________________________State:____________________
Name of Person doing Start-up (print) __________________________________________________________________________
Company Name ___________________________________________________________________________________
Address__________________________________________________________________________________________
City/State/Zip______________________________________________________________________________________
Unit Model No.: ___________________________________________ Unit Serial No.: ____________________________________
Compressor No. 1 Model No.:________________________________ Serial No.: ________________________________________
Compressor No. 2 Model No.:________________________________ Serial No. : _______________________________________
Compressor No. 3 Model No.:________________________________ Serial No.: ________________________________________
Compressor No. 4 Model No.:________________________________ Serial No.: ________________________________________
Compressor No. 5 Model No.:________________________________ Serial No.:________________________________________
Compressor No. 6 Model No.:________________________________ Serial No.:________________________________________
Circle "Yes" or "No". Mark N/A on all items not applying to the type of the unit. See IM Bulletin for more information.
Any additional comments may be made on a separate sheet of paper and attached to this form.
I. INITIAL CHECK
A. Is any shipping damage visible? .......................................................................................................................... Yes No
B. Are fan drives properly aligned and belts properly adjusted? .............................................................................. Yes No
C. Tightened all setscrews on pulleys, bearings and fans? ...................................................................................... Yes No
D. Have the hold-down bolts been backed off on spring mounted fan isolators?..................................................... Yes No
E. Do fans turn freely?.............................................................................................................................................. Yes No
F. Has the discharge static pressure reference line been properly located within the building?.............................. Yes No
G. Electrical service corresponds to unit nameplate?............................................................................................... Yes No
Volts _____ Hertz______ Phase_____
H. Is the main disconnect adequately fused and are fuses installed? ...................................................................... Yes No
I. Are crankcase heaters operating, and have they been operating 24 hours prior to start-up? ............................. Yes No
J. Are
all
electrical power connections tight? (Check compressor electrical box) ................................................... Yes No
K. Is the condensate drain trapped?......................................................................................................................... Yes No
II. FAN DATA
A. Check rotation of
Supply
fan? ............................................................................................................................. Yes No
B. Voltage at Supply fan motor: 1-2 ________ V 2-3 ________ V 1-3 ________V
C. Supply fan motor amp draw per phase: ___________ L1 ____________ L2 ___________ L3
D. Fuse sizes ........................................... ____________________________________________
E. What is the Supply fan rpm? ............................................................... ____________________
F. Check rotation of
Return
fan?.............................................................................................................................. Yes No
G. Voltage at Return fan motor: 1-2 __________ V 2-3 _________ V 1-3 ________V
H. Return fan motor amp draw per phase: ___________ L1 ______________ L2___________ L3
I. Fuse sizes ........................................... _____________________________________________
J What is the Return fan rpm? ............................................................... _____________________
K. Record supply static pressure at unit ........................................................................................... _______________ Inches of H
2
O
L. Record return static pressure at unit (with outside air dampers closed) ...................................... _______________ Inches of H
2
O
III. START-UP COMPRESSOR OPERATION
A. Do compressors have holding charges?
Circuit #1 .............................................................................................................................................................. Yes No
Circuit #2 .............................................................................................................................................................. Yes No
B. Backseat discharge, suction and liquid line valves? ............................................................................................ Yes No
C. Are compressors rotating in the right direction?................................................................................................... Yes No
D. Do condenser fans rotate in the right direction?................................................................................................... Yes No
E. Ambient Temperature........................................................................................................................................... _____ °F
Rooftop Equipment Warranty Registration Form:
This form must be filled out and returned to McQuay, Warranty Department,
within 10 days in order to comply with the terms of McQuay Warranty.
To Next Page
