56 OM Centrif Micro ΙΙ-5
SET COMP#N SPs (3)
StageDeltaT= X.X°
°°
°F
Stop-Start = xx min.
Start-Start =xx min.
SET COMP#N SPs (4)
SET COMP#N SPs (5)
OilNoStrtDiff=XX°
°°
°F
Abs Capacity=XXXXT
HotGasBypass = XX%
SET COMP#N SPs (6)
UnloadTimer=XXXsec
PrelubeTmr=xxxsec
PostlubeTmr=XXXsec
Be fore E nter ing Edi t M ode A ft er En te ri ng E dit M od e
SET COMP#N (7)
SET COMP#N (7)
VaneMode=AUTO
VaneMode=AUTO <AUTO
Vanes=UNKNOWN
Vanes=UNKNOWN <LOAD
%RLA = XXX%
%RLA = XXX% <UNLD
VaneMode settings can be AUTO or MAN (Manual) as determined from the Vane Mode setpoint.
Vanes position is indicated as CLOSED or UNKNOWN as determined from the Vanes Closed
switch
di
gital
input.
When
Edit
mode
is
selected
o
n
this
s
creen,
the
<AUTO/<LOAD/<UNLD
prompts will appear. Holding the “LOAD” key will then continuously load the compressor and
holding the “UNLD“ key will unload it. After releasing either key the compressor will “hold” and
the Vane Mode setpoint will be set to Manual. Pressing the AUTO” key will set the Vane Mode
back to
Auto.
After
leaving edit mode the <AUTO/<LOAD/<UNLD prom
pts wil
l be hidden.
The following VFD screen will only be shown if the VFD set point = YES.
Be fore E nter ing Edi t M ode A ft er En te ri ng E dit M od e
SET COMP#N (8)
SET COMP#N (8)
VFD Mode=AUTO
VFD Mode=AUTO <AUTO
VFD = XXX%
VFD = XXX% <LOAD
%RLA = XXX%
%RLA = XXX% <UNLD
VFD Mode settings can be AUTO or MAN (Manual) as determined from the VFD Mode setpoint.
VFD speed is shown as 0 to 100%. When Edit mode is selected on this screen, the
<AUTO/<LOAD/<UNLD prompts will appear. Holding the “LOAD” key will then continuously
speed up the VFD and holding the “UNLD“ key will slow it down. After releasing either key the
VFD will stay at the current speed and the VFD Mode setpoint will be set to Manual. Pressing the
AUTO” key will set the VFD Mode back to Auto. After leaving edit mode the
<AUTO/<LOAD/<UNLD prompts will be hidden.
