5.2.3 Footswitch - stirrup opening

WARNING:
ThefootswitchisspecicallydesignedtobeusedonlywiththePiezosurgeryMedicaldevice.Only
useoriginalPiezosurgeryMedicalfootswitchasotherwisedamageormalfunctionmayoccur.
- Rotatethemetalstirrupuntilitisxedinverticalposition(Pic.8-Ref.A).
- Rotateandmanuallyfastenthelateralclampstosecurethestirrupinthecorrectposition(Pic.8
-Ref.B).
5.2.4 Connecting the footswitch connector to the body of the device.
- Insert the connector of the footswitch cable into the corresponding connector placed on the
backofthedeviceandmarkedwiththespecialsymbolasindicatedinPic.9.Todisconnectthe
footswitchfromthedevicebody,holdtheconnector,pressthereleasetabandpullback.

WARNING:
Donotattempttotwistorrotatetheconnectorofthefootswitchcablewhileinsertingorremoving.
Twistingmaydamagetheconnector.

WARNING:
Toavoiddamagingthefootswitchcable,connectand/ordisconnectalwaysholdingonlytheconnector.

WARNING:
Alwayscheckbeforeandafterusethatthefootswitch,thecableanditsconnectorarenotdamaged.
Ifdamageisdetecteddonotusethefootswitch.
Pic.9
