 Manualofuseandmaintenance
5.2 Assembly and switching on the system
Beforeoperatingitisnecessarytoassemblethesystemasdescribedinthefollowingsteps:
5.2.1 Additional earth connection
- Ifrequired,insertadditionalearthingtothecorrespondingconnector(Pic.7-Ref.A).
5.2.2 Power supply cable connection
- Insertthepowersupplyconnectorintheconnectorplacedonthebackofthedevice(Pic.7-
Ref.B)andthentothewallsocket.
Pic.7
C
AB
D
E
Pic.8
A
B
