mectron Piezosurgery - 7 Replacing the Fuses

Manualofuseandmaintenance
EN
85
7 REPLACING THE FUSES

DANGER: Switch off the device.
Beforereplacingthefuses,alwaysswitchoffthedevicefromthemainswitch(Pic.7-Ref.C)and
disconnectfromthepowersupply.
1. Gentlyleverwithascrewdriverplacingthepointontheseatofthefuseboxunderthepower
supplysocket(Pic.26-Ref.A).
2. Extractthefusebox(Pic.26-Ref.B).
3. Replacethefuses,respectingthecharacteristicsindicatedontheIDtagplacedonthebackof
thedevice.
4. Reinsertthefuseboxinitslodging.

DANGER:
Takespecialcareinrespectingthetechnicalcharacteristicsofthefuses.Thefusesmustbeofthe
5x20mmT2AL,250Vkind.
Pic.26
A B
