76
 Manualofuseandmaintenance
- Thefunctionswhichtheusercanselectfromthescreenarethefollowing:
Pic.17-Ref.D INFObutton-Graphicdisplay,uppersection.
Function Enables the operator to view the technical description of the corresponding
insert.
Pic.17-Ref.E Pagebuttons-Graphicdisplay,uppersection.
Function Enablestheoperatortochangetheviewinsertspage.
Pic.17-Ref.B Handpiecen°1workstation-Graphicdisplaycentralleftsection.
Functions -Selectionofpowerinrelationtothebonetotreat:
 CORTICAL:highlymineralized,densebone.
 CANCELLOUSMEDIUM:averagemineralizationcancellousbone.
 CANCELLOUSLOW:lowmineralizationcancellousbone.
 DELICATEANATOMY:bonewithamaximumthicknessof1mmorinproximity
ofneurologicalsofttissues.
 -Choiceofquantityofliquidtodeliverusingthe+/-keysintheIRRIGATION
eld.
 -Choiceoflevelofpowerrequiredusingthe+/-keysoftheVIBRATIONeld.
Pic.17-Ref.C Handpiecen°2workstation-Graphicdisplaycentralrightsection.
Functions
 -Selectionoftypeofpowerinrelationtothetypeofbonetotreat:
 CORTICAL:highlymineralized,densebone
 CANCELLOUSMEDIUM:averagemineralizationcancellousbone.
 CANCELLOUSLOW:lowmineralizationcancellousbone
 DELICATEANATOMY:bonewithamaximumthicknessof1mmorinproximity
ofneurologicalsofttissue
 -Choiceofquantityofliquidtodeliverusingthe+/-keysintheIRRIGATION
eld.
 -Choiceoflevelofpowerrequiredusingthe+/-keysoftheVIBRATIONeld.
Pic.11-Ref.A LANGUAGEbutton-Graphicdisplay,lowersection.
Function Enablestheoperatortoselectanewlanguage.
Pic.17-Ref.F SHUTDOWNbutton-Graphicdisplay,lowersection.
Function Enablestheoperatortoshutdowntheworksectioncorrectly.
Pic.17-Ref.G PUMPbutton-Graphicdisplay,lowersection.
Function This button enables the operator to ll the irrigation circuit with the solution
containedinthephysiologicalsolutionbag.
 NOTE:ThePUMPbuttononlyappearsafterahandpiecehasbeenconnected
tothedevicebodyinthecorrespondingposition.
