Unpacking your Discovery Seat
Remove all the packaging and check that you have received all the parts you
ordered.
Tools required to adjust your Shuttle Discovery are a 10mm ring spanner/socket
and 4mm hex allen key.
WARNING
Ensure children do not play with packaging material, especially
the plastic bags.
1. Occipital support headrest
pad
2. Padded shoulder strap
3. Thoracic laterals
4. Backrest laterals
5. Hip supports
6. Seat cushion
7. Seat release knob
8. Elevated footplate
9. Seat tilt in space
10. Tray receiver
11. Sunhood receiver
12. Headrest support wings
(exterior)
1
2
3
4
5
6
7
8
9
10
11
12
