Medifab Shuttle Discovery - Lunar Base; Installing the Discovery Seat

54
Lunar Base
For safety reasons, the seat will only install one way into the base.
The notch (B) in the seat side engages into the crossbar to ensure this.
WARNINGS
1. The two red safety plungers (C) should self-lock onto the
front mounting bar.
2. Always check that the two red safety plungers have engaged
and that the seat is secure before using the seat.
3. Be aware of the length of the base and the surrounding in
which the Lunar Base is being used.
4. Do not allow other individuals to use, play with, stand on,
climb on or run / play around the Lunar Base.
5. Always use the Lunar Base on an indoor level surface.
6. Always use all of the positioning straps provided.
Installing the Discovery Seat
Angle the rear of the Discovery Seat into the Lunar Base. Slide the rear slot on the
seat onto the rear mounting bar of the Lunar Base.
Press the front of the seat down onto the front mounting bar (A) of the Lunar
Base.
C
A
B
Lunar Base
