Adjusting the height
To adjust the height of the Lunar Base, remove the outer screws (A) whilst
holding the T nuts (B) with the other hex allen key. Reposition the leg to the
desired height and retighten the screws into the T nuts (B).
Removing the Discovery Seat
Release the red safety plungers by pulling the red knobs (C). Once the front of
the seat is free, tilt the seat back and remove seat from the rear mounting bar.
WARNINGS
1. Never adjust the height of the Lunar Base with the user
seated in the Discovery Seat.
2. Ensure all four legs are level and secure before placing the
user into the Discovery Seat.
3. For the ease of adjustment we recommend that the height
of the Lunar Base is adjusted without the Discovery Seat
mounted on the Lunar Base.
WARNINGS
1. Always hold the Discovery Seat properly with both hands.
Otherwise the seat could fall and cause damage.
2. Never install or remove the Discovery Seat with the user
sitting in the seat.
Lunar Base
A
B
C
