Medifab Shuttle Discovery - Installing the Discovery Seat; Forward Facing; Rear Facing; Removing the Discovery Seat

26
Forward Facing
Before installing the Discovery Seat into the Verve Stroller, engage the parking
brake.
Angle the rear of the Discovery Seat into the stroller. Slide the rear slot on the
seat onto the rear mounting pegs (A) of the stroller.
Lower the front of the seat down onto the front mounting bar (B) of the stroller.
The two red safety plungers (C) should self-lock onto the front mounting bar. If
not, press down on the front of the seat.
Ensure both safety plungers are engaged
by trying to lift the seat while holding
down the stroller.
Rear Facing
Angle the rear of the Discovery Seat into the front of the stroller. Slide the rear
slot on the seat onto the front mounting bar (B) of the stroller.
Press the front of the seat down onto the rear mounting bar of the stroller.
The two red safety plungers (C) should self-lock onto the rear mounting bar. If
not, press down on the front of the seat.
The tray can NOT be tted onto the Discovery Seat when the seat is in a rear
facing position.
WARNINGS
1. Always check that the two red safety plungers have engaged
and the seat is secured before using the seat.
2. Be aware of the length of the base and the surroundings in
which the Shuttle Discovery is being used. Always use all of
the positioning straps provided.
WARNINGS
1. Always hold the Discovery Seat properly with both hands.
2. Never install or remove the Discovery Seat with the user
sitting in the seat.
Removing the Discovery Seat
Before removing the Discovery Seat from the Shuttle Discovery engage the
parking brake.
Release the red safety plungers by pulling the red knobs (C). Once the front of
the seat is free tilt the seat back and remove seat from the rear mounting bar.
A
B
C
Installing the Discovery Seat
WARNING
Always check that the two red
safety plungers have engaged
and the seat is secured before
using the seat.
