Fitting the pelvic strap
Feed the pelvic strap through the slot (A) in the seat depth bracket (B).
Secure the straps with the triglide buckle (shown in image at right).
1. 2. 3. 4.
Accessories: 5 Point Harness
B
A
B
Securing the pelvic strap
Push the male and the female parts of the side release buckle together.
To release the buckle press the two slide release clips.
Adjusting the pelvic strap
The length of the pelvic straps can be adjusted with the triglide (shown
in image at right) and the length of webbing through the slot located
on the seat depth bracket.
Ensure the pelvic webbing is securely fed through the triglide as shown.
Triglide buckle
