Medifab Shuttle Discovery - Foot Straps & Footplate Accessories; Fitting the Toe & Ankle straps; Footplate over-cover; Footplate Dorsiflexion wedge

48
Fitting the Toe & Ankle straps
Pass the Velcro straps through the footplate at the desired width for the user’s foot.
Then connect the straps together (A) as shown under the footplate.
Footplate over-cover
Fit the padded footplate cover with Velcro as shown.
Footplate Dorsiexion wedge
Fit the Dorsiexion wedge with slope going back. i.e. with thick edge (B) at front
and thin edge (C) at rear.
A
B
C
Accessories: Foot Straps & Footplate Accessories
