63
www.shuttlediscovery.com
Lunar Base: 2006-0013-000
Frame width 43 cm / 17"
Frame length 63 cm / 24.8"
Frame height 17-28 cm / 6.7-11"
Seat to oor height 22-32 cm / 8.6-12.6"
Load capacity 40 kg / 88.1 lb
Weight 2.5 kg / 5.5 lb
Moon Rock Base: 2006-0011-000
Frame width 41 cm / 16.1 lb
Frame length 71 cm / 22.9"
Frame height 27.5 cm / 10.8"
Seat to oor height 34 cm / 13.3"
Load capacity 40 kg / 88.1 lb
Weight 3.4 kg / 7.4 lb
Servicing & Technical Data
Launcher Base: 2006-0012-000
Frame width 61 cm / 24"
Frame length 73 cm / 28.17"
Frame height 54 cm / 21.3"
Seat to oor height 38-68 cm / 15-26.8"
Load capacity 40 kg / 88.1 lb
Weight 9.2 kg / 20 lb
Medifab Service Distributor
Please record the Medifab Distributor from which you purchased your Shuttle Discovery.
Company
Address
Phone Website
Contact Email
Serial #
Shuttle Discovery
Overall length with legrest 93 cm / 36.6"
Overall width 65 cm / 25.6"
Folded length 84 cm / 33"
Folded width 65 cm / 25.6"
Folded height 61 cm / 24"
Total Mass 20 kg / 44 lb
Mass of the heaviest part 12.5 kg / 27.6 lb
Static stability downhill 0-10°
Static stability uphill 0-10°
Static stability sideways 0-10°
Seat plane angle 90-160°
Eective seat depth 14-30 cm / 5.5-11.8”
Eective seat width 13-27 cm / 5.1-10.6”
Seat surface height at
front edge
64 cm / 25.2"
Backrest angle 90-60°
Backrest height 45-58 cm / 17.7-22.8”
Footrest to seat distance 14-28 cm / 5.5-11”
Leg to seat surface angle 90-160°
