MediSono P12 - Rotation; Biopsy

Digital Color Doppler Ultrasound System
86
Basic User Manual
NOTE:
Image orientation can be changed in real time mode as well as in frozen mode.
6.2.16 Rotation
Rotation function can rotate the image to a certain angle. The options contain 90°, 180°, and
270°.
Instructions:
1. Open the menu, and use the trackball to select ROT .
2. Rotate to select rotation angle.
6.2.17 Biopsy
Biopsy
Gun
Biopsy Type
Gun
Biopsy Angle
-1.0
Biopsy Offset
40. 0
You can enable or disable the biopsy feature in the real time mode. When Biopsy is set to
Needle , two biopsy guide lines appear. When Biopsy is set to Gun , only one biopsy guide line
appears.
Instructions:
1. Open the menu, and use the trackball to select Biopsy .
2. Rotate to make settings of Biopsy , Biopsy Type , Biopsy Angle and Biopsy
Offset .
NOTE:
 The adjustment ranges of Biopsy Offset and Biopsy Angle vary with the probes.
 You should calibrate the biopsy guideline each time before performing biopsy. Do not use
a needle guide if the pat h of the needle is not accurately indicated by the on-screen
guidelines. The path of the needle must display within the guidelines.
 The values of Biopsy Offset and Biopsy Angle restore to defaults after system reboot.
2. Rotate
to reverse the image.
