2
Introduction
Breaker Analyzer EGIL is intended for use in medium-
voltage substations and industrial environments and is
designed to test medium-voltage circuit breakers with
no more than one main contact per phase. If the main
contacts are equipped with parallel pre-insertion resis-
tor contacts, EGIL automatically records the difference
between main and resistor contacts. Auxiliary contact
timing as well as coil current traces are recorded.
As option, EGIL can be equipped for travel motion
recording and with a USB interface for PC-communi-
cation.
Options
Option - >
All options in this manual start with lines as above
and stop with lines as below.
Option - End
10 EGIL ZP-BM01E BM0087OE
2 INTRODUCTION
