7.1 Parameter values
There is a default set of parameter values, allowing
you to start EGIL and run a complete measurement
without changing anything. This set of default values
are permanently stored in memory DEFAULT and can-
not be changed.
You can define your own parameter values by using
either the SEQUENCE menu or the MAIN menu. Up to
ten sets of values can be saved for future use, and you
can decide which set that should be used as start-up
values by storing it in memory number 0 (zero).
7.2 The SEQUENCE menu
The SEQUENCE menu is displayed when you start EGIL
and is used to define functions of the trip/coils on the
breaker.
You specify all the time parameters needed to gener-
ate a measurement sequence by choosing between
the following time parameters. They correspond to
the chronogram showed below.
C Close-pulse
CO Close-Open pulses
O Open pulses
OC Open-Close pulses
OCO Open-Close-Open pulses
The chronogram below shows how pulses and pulse
delays are defined:
