4
System components
4.1 Standard items
EGIL standard unit includes the following
Item Art. No.
Basic unit EGIL, BM-19076
Mains cable, 2.5 m (8.2 ft) 04-00XXX
Breaker control cables, black, 2x2 m (6.6 ft) 04-35030
Breaker control cables, red, 2x2 m (6.6 ft) 04-35032
Fuse, 12A F, 6.3 x 32 mm 33-07147
Cable, Extend, 10 m (32.8 ft) GA-00150
Cable, TIMING, 5 m (16.4 ft) GA-00160
Cable, AUX1&2, 2 m (6.6 ft) GA-00170
Protective cable, 2.5 m (8.2 ft) GA-00200
Thermal printer paper, 2 rolls GC-00030
Transport case GD-00190
EGIL User’s guide ZP-BM01E
Cable tie, 13 x 225 mm (0.5" x 8.8") 9 pcs 19-62200
EGIL extended unit includes the following
Basic unit EGIL, with MOTION channel
and USB interface
BM-19079
Basic unit EGIL, with SDRM, MOTION
channel and USB interface
BM-19075
Mains cable, 2.5 m (8.2 ft) 04-00XXX
Breaker control cables, red, 2x2 m (6.6 ft)) 04-35030
Breaker control cables, red, 2x2 m (6.6 ft) 04-35032
Fuse, 12A F, 6.3 x 32 mm 33-07147
Cable, 1 m (3.3 ft), XLR - female GA-00041
Cable, 7.5 m (24.6 ft), XLR GA-00042
Cable, Extend, 10 m (32.8 ft) GA-00150
Cable, TIMING, 5 m (16.4 ft) GA-00160
Cable, AUX1&2, 2 m (6.6 ft) GA-00170
Cable, USB HG-00000
Protective cable, 2.5 m (8.2 ft) GA-00200
Thermal printer paper, 2 rolls GC-00030
Transport case GD-00190
EGIL User’s guide ZP-BM01E
Cable tie, 13 x 225 mm (0.5" x 8.8") 11 pcs 19-62200
4.2 Accessories
The following accessories can be ordered
Accessory Art. No.
Extension cable Timing & AUX 1&2, 10 m
(33 ft)
GA-00150
Transducer TLH 500, 500 mm (19.6”) stroke XB-30020
Transducer TS 150, 150 mm (5.9”) stroke XB-30030
IP6501, rotates through 357° XB-31010
Assembly kit for TLH, TS or IP6501 XB-51020
For other lengths of TLH, TS.
Contact Megger Sweden AB
16 EGIL ZP-BM01E BM0087OE
4 SYSTEM COMPONENTS
