5
Description
5.1 Fields of application
EGIL is primarily intended for:
• Time measurement
• Automatic coil current measurement
• Travel motion measurement
Time measurement
There are two time measuring connections:
The TIMING connection with three time channels. Sig-
nals can be measured at both main contacts and pre-
insertion resistor contacts on the same channel. EGIL
automatically senses if there is a pre-insertion resistor
connected. No specific settings are necessary.
The AUX1&2 connection with two independent
auxiliary inputs. These inputs can be used for contact-
sensing or voltage-sensing.
The time for contact operations is measured in several
different sequences (open/close).
The maximal measurement time for EGIL is 100 sec-
onds.
Automatic coil current
measurement
The breaker coil current is measured by a built-in and
fully insulated current sensor during the measured
operating sequence.
Breaker operation sequence
A built-in sequencer automatically sets the instrument
for the next sequential breaker operation. The opera-
tor can select other operation sequences using the
arrow keys of the keyboard, see section 9.2.
Other functions
The keyboard is used for entering control parameters
via the menu system.
The display shows the settings and can also be used
for result read-out.
Test reports can be printed after each measurement
sequence.
Option - >
Options
As an option, EGIL can be equipped with a motion
measurement input. An analog channel gives you
the ability to measure motion (using resistive motion
transducers) or for voltage or current measurements.
EGIL can also be equipped with an optional USB
interface for communication with a personal com-
puter. This will support communication with the CABA
analysis program.
As a third option EGIL can be equipped with SDRM
functionality for static and dynamic resistance meas-
urement.
Option - End
18 EGIL ZP-BM01E BM0087OE
5 DESCRIPTION
