10
Connecting EGIL to a
computer
(option)
Option - >
If EGIL is equipped with a connector marked USB.
EGIL can be connected to a computer in which the
CABA Breaker Analysis program has been installed.
This enables you to:
• store settings and test parameters for individu-
al breakers in the computer
• make quick evaluations and comparisons
• print out reports
• store test results in the computer
The communication proceeds via the computer’s USB
port and the USB cable which is included when you
purchase CABA for EGIL.
Note If you do not use the included USB cable,
make sure that the cable you use instead is a
standard USB cable.
The version R03B or a later version of the CABA
Breaker Analysis program must be installed in the
computer.
10.1 Connecting the
computer
Note A driver for the USB port on the EGIL must be
installed before you can use the USB port. The
USB driver is on the CABA Win CD ROM.
To connect EGIL to the computer you must take the
following steps in the sequence shown below:
1] Connect the cable included with CABA for
EGIL between EGIL’s USB port and the com-
puter’s USB port.
2] Start the computer.
3] Turn on power to EGIL.
4] Start CABA.
54 EGIL ZP-BM01E BM0087OE
10 CONNECTING EGIL TO A COMPUTER (OPTION)
