44
FRAX User's Manual
© 2011 Megger Sweden AB
FRAX fast
40
20 - 200
40
60
200 - 2 k
60
80
2 - 20 k
80
100
20 - 200 k
100
160
200 k - 2 M
160
Total:
440
37
Fixed P/D
settings
Example
100
20 - 2 M
500
Omicron default
160
20 - 2 M
800
76
Doble default
200
20 - 2 M
1000
93
Omicron max
320
20 - 2 M
1600
145
Doble max
360
20 - 2 M
1800
163
FRAX max
6400
20 - 2 M
32000
4.3.4 Graph Settings... (Ctrl+G)
In the Graph settings dialog you set auto scale or range and spacing for the axis. The Dialog
has one tab for the Magnitude and one tab for Phase, as well as a tab for the combination of
Magnitude and Phase. In the bottom you have a check box that makes changes that affect all
graphs.
