5.5 Appendix E: FRAX cables and clamps
The FRAX clamps and cables are field tested, rugged accessories ensuring repeatable and
accurate measurements. Coaxial cables are covered with an extra protective cover and strain
relief is fitted on all 9 and 18 meter cables to ensure a long and trouble free life of service.
Ground braids made of tin plated copper ensure good contact, make them easy to work with
and increase life of service compared to e.g. aluminium.
The FRAX clamps handles both round and flat connectors. Easy to attach and a firm grip
avoids any risk of clamps falling off.
The C-clamp is used to connect the FRAX to the bushing. All necessary connectors (BNC, braid,
ground, cable strain relief) are included in one clamp. The smaller G-clamp is used to connect
the braids to ground. Both models are part of the standard cable set delivered with a FRAX.
