5.5.1 Bushing connection
The C-clamp can be fastened on any type of bushing up to Ø 90 mm. The M12 screw ensures
good electrical and mechanical contact. No risk of a clamp falling down due to heavy cables
and braids.
The clamp is delivered with a M12 hat nut, which can be used when you want to avoid the
screw making marks on a sensitive surface.
