The analyzer calculates the relative factor Rxy from the correlation LRxy and implementation is only possible
using SFRA Magnitude in dB-scale.
NOTE
Calculations of LRxy and LRxy is based on discrete mathematics described under the DL/T
911-2004 Analyzer section below. Therefore, same traces measured with logarithmic or linearly
spaced measurement points will give slightly dierent result. Mathematics describing a continu-
ous trace is best approximated using linear spaced measurement points.Furthermore, the DL/T
911-2004 standard also assumes linearly spaced measurement points.
5.16. Exit (Alt+F4)
Terminates the FRAX software.
5.17. Connect
Same as the menu item Connect (F7).
FRAX Software
52 FRAX-series www.megger.com
