Megger FRAX Series User Manual

5.3. File Menu
Menu action Short- cut Description
New File (Ctrl+N) Creates a new measurement le to save data in
Load File (Ctrl+L) Loads a previous performed measurement le
Select File (Ctrl+F) open the le database to be able to select one or more les to open
Close File (Ctrl+I) Close a measurement le
Custom Report Creates a report using MS Word report templates
Export (Alt+E) Export active measurements to a *.csv or *.txt le
Import (Alt+I) Load les in other le formats.
Report Creates a simple report in MS Word, pdf and html formats
Add Test (Ctrl+A) Adds an additional test into a measurement le
Delete Test (Ctrl+D) Deletes a test (performed or empty) from a measurement le
Edit nameplate (Ctrl+E) opens the measurements le nameplate to allow editing
Dierence (Alt+D) Calculates the dierence between two tests active in the graph and plot
results
Connect (F7) Connect the FRAX software to the FRAX instrument
Disconnect (F8) Disconnect the FRAX software from the FRAX instrument
Start Measurement (F9) Start measurement of selected test in test browser
Stop Measurement (F10) Stop active measurement
Recent les The latest les opened.
Exit (Alt+F4) Terminates the FRAX Software
New File (Ctrl+N)
The software requires a le and a folder location to save its data.
1] The command “New File” opens the “Save As…” dialog.
Measurement Type
1. In “Measurement type” window, select tab:
Single Test Make a single test with the Test label of choice.
Multiple Tests To use and design “Test groups” containing one or more tests.
Use Measurement as Tem-
plate
To use an earlier performed measurement as template for a new measurement.
In the “Single Test” tab
1. Enter the “Test name”
2. Press “OK”.
In the “Multiple Tests” tab
1. Select one of the pre-dened test templates containing one or more tests.
2. To modify the pre-dened test plans, use the buttons “Add” and “Delete”. The names can be changed by
selecting a “Test group” or “Test name” and enter a new name.
3. Select a “Test group” and select which tests that should be included by setting the cross in front of the
test name(s) and then press “OK”. For more information see Appendix D.
FRAX Software
28 FRAX-series www.megger.com
