NOTE
The “Measurements Settings” in “Single Test” and “Multiple Tests” are taken from the FRAX
measurement settings in the conguration menu. However, the “Measurement settings” can be
changed test by test in the legend before performing the measurements.
In the “Use Measurement as Template” tab
1. Select an earlier measurement as template for the new measurement.
2. Press the “Load File” button and load the Measurement le or use “Select File” to nd an earlier
measurement in the database.
3. The “Test names” in the selected previous measurement are shown. An “X” indicates the tests in the
selected le were actually measured last time. The tests to be included must be checked and those not
included unchecked. Then press “OK”. The test names and measurement settings used in the selected
le are loaded.
Nameplate
If “Single Test” or “Multiple Tests” are selected in the “Measurement type” dialog, an almost empty nameplate
will appear. The “Test date:” is by default lled in with PC system date.
FRAX Software
www.megger.com FRAX-series 29
