30
SVERKER 750/760
Programma Electric AB
ZP-CD01E R05A
5.4 The menu system
Menu level 1 Menu level 2 options Explanation
Test mode Normal Measures time from START to STOP.
Trip + pulse time Measures time from START to STOP and also the duration of the trip
pulse.
Reclose: #01 999 s Sets time for reclosing. Max 49 reclosings. The total time for the
specified number of reclosings can range from 001 to 999 s.
Injection Maintained Generation continues without time limit.
Momentary Generation continues while button is kept pressed.
Max time 99.9 s Generation continues throughout a preset interval that
can range from 00.1 s to 99.9 s.
External start See section 5.6
Ammeter AC Measures AC, true RMS.
DC Measures DC, mean value.
Unit: Ampere Expressed in amperes.
Unit: % of nom I Expressed as % of nominal current.
Nom I: 001 A Used to set nominal current.
Range: Auto Range selected automatically.
Range: Low Fixed low range.
Range: High Fixed high range.
Voltmeter AC Measures AC, true RMS
DC Measures DC, mean value
Shunt (1 - 999 mΩ) Default shunt value is 100 mΩ. Displayed value is shown in A or kA.
Unit: Volt Expressed in volts.
Unit: % of nom U Expressed as % of nominal voltage.
Nom U: 063 v Used to set nominal voltage.
Range: Auto Range selected automatically.
Range: Low Fixed low range.
Range: Mid Fixed mid range.
Range: High Fixed high range.
Q , ϕ , W ,VA None No extra measurement function displayed
Z (Ω. ϕ) Impedance (magnitude + phase angle)
Z (Ω) Impedance (magnitude)
R. X (Ω. Ω) Resistance and reactance (magn and magn)
P (W) Active power
S (VA) Apparent power.
Q (VAr) Reactive power.
cos ϕ Power factor.
ϕ (°, Iref ) Phase difference, current as reference.
ϕ (°, Uref ) Phase difference, voltage as reference.
Timer Unit: Seconds Time expressed in seconds.
Unit: Cycles Time expressed in mains-frequency cycles.
Display Slow Average-value filter enabled, thereby stabilizing the display. 10 values
are used to create the average. Phase difference is not filtered.
Fast Average-value filter disabled.
Hold Trip Shows the max value in RMS for 1 period immediately before tripping.
Hold Max Shows the max value in RMS for 1 period within the last 0.5 s held in
memory.
Hold Min Shows the min value in RMS for 1 period within the last 0.5 s held in
memory.
Off delay Cycles 004 Mains-frequency cycles throughout which generation is to continue
after tripping occurs.
0-Level filter 1-9 To avoid measuring noise that can be encountered during testing. A 0-
level of 1 (min.) allows low-level signals to pass. A 0-level of 9 (max.)
filters out most noise.
Save/Recall Recall mem #: O Recalls all settings that were stored in the specified memory.
Range is O-3.
Recall default Recalls all of the original settings made by Programma prior to delivery
(they are stored in a special memory).
Save mem #: 0 Saves the settings in the specified memory. The range is 0-3.
