32
SVERKER 750/760
Programma Electric AB
ZP-CD01E R05A
5.5 Test mode
Test mode
<Normal>
This menu option is used to specify the desired type
of time measurement. You have three choices:
Normal, Trip + pulse time and Reclose.
You press the CHG button to access the different
memory options, and then scroll up or down using
thes or t button.
Menu option Explanation
Normal
Measures time from START to STOP.
Trip + pulse time
Measures time from START to STOP
and also the duration of the trip
pulse.
Reclose: #01 999 s
Sets time for reclosings. Max 49
reclosings. The total time for the
specified number of reclosings can
range from 1 to 999 s.
1. Press the SEL button to invoke the se-
lected option.
5.6 Injection
Injection
<Maintained>
Here, you select the type of generation. You have
four choices: Maintained, Momentary, Max time
and External Start.
Menu option Explanation
Maintained
Generation continues without any time
limit.
Momentary
Generation continues while start switch
is kept activated.
Max time: 99.9 s
Generation continues throughout a
preset interval that can be set from
00.1 to 99.9 s. IMPORTANT: To change
a numerical value, press the CHG
button one additional time and then
use the arrow buttons.
External Start
Select dry or wet contact and closing or
opening contact for the external signal.
This feature enables you to start two or
more Sverkers simultaneously. The
Sverkers “slaves”can be connected to
the make/break contact on the Sverker
“master” and then be set for external
start. The slaves will start at the same
time as the master (±1 ms).
1. Press the SEL button to invoke the se-
lected option.
