132
8: Multi-stage reference terminal 3
9: Multi-stage reference terminal 4
Table 6-7 Table of multi-speed running options
K
4
K
3
K
2
K
1
Frequency setting
OFF OFF OFF OFF Common running frequency
OFF OFF OFF ON Multi-stage frequency 1
OFF OFF ON OFF Multi-stage frequency 2
OFF OFF ON ON Multi-stage frequency 3
OFF ON OFF OFF Multi-stage frequency 4
OFF ON OFF ON Multi-stage frequency 5
OFF ON ON OFF Multi-stage frequency 6
OFF ON ON ON Multi-stage frequency 7
ON OFF OFF OFF Multi-stage frequency 8
ON OFF OFF ON Multi-stage frequency 9
ON OFF ON OFF Multi-stage frequency 10
ON OFF ON ON Multi-stage frequency 11
ON ON OFF OFF Multi-stage frequency 12
ON ON OFF ON Multi-stage frequency 13
ON ON ON OFF Multi-stage frequency 14
ON ON ON ON Multi-stage frequency 15
Table 6-8 Expression of multi-stage closed loop reference selection
Multi-stage closed
loop terminal 4
Multi-stage closed
loop terminal 3
Multi-stage closed
loop terminal 2
Multi-stage closed
loop terminal 1
Multi-stage closed loop
reference selection
OFF OFF OFF OFF
The closed loop reference is
determined by P14.02.
OFF OFF OFF ON
Multi-stage closed loop
reference 1
OFF OFF ON OFF
Multi-stage closed loop
reference 2
OFF OFF ON ON
Multi-stage closed loop
reference 3
OFF ON OFF OFF
Multi-stage closed loop
reference 4
OFF ON OFF ON
Multi-stage closed loop
reference 5
OFF ON ON OFF
Multi-stage closed loop
reference 6
OFF ON ON ON
Multi-stage closed loop
reference 7
ON OFF OFF OFF
Multi-stage closed loop
reference 8
