3 Setup and installation
16
Fitting the device on a floor unit
In order to fit the device on a floor unit, proceed as follows:
1. Unscrew both rear casters including rails using a
5mm ball-head Allen key. Reuse the screws to
secure the bracket.
2. Unscrew and remove both fore device feet and the
rear device foot using an open-end wrench
(size24).
3. Place the 3mm flat washers on both fore pins on the
corners of the floor unit.
4. Place the 3mm flat washers on both rear holes on the
corners of the floor unit.
5. Place the MELAtherm on the floor unit.
