3 Setup and installation
17
6. Screw the two brackets (scope of delivery of the
floor unit) on the MELAtherm and the floor unit
using the screws and flat washers (see pos. a).
7. The closed side of the bracket must point outwards.
8. Secure the device with floor unit on the wall with the aid of the wall fixture, see "Instructions for
installing the wall fixture" (doc.: AS_025-17).
