4 Description of the device
15
PLEASE NOTE
The energy-saving mode can not be activated during a program run.
State Meaning
Lighted The energy-saving mode can be activated.
Not lighted The energy-saving mode can not be activated.
Colour-touch display
The operating panel consists of a colour 5 inch touch display.
Status bar
Menu bar
Main area
Action bar
Symbols in the status bar Meaning
Program/tests Indicates whether a program/test is running
Immediate output Indicates whether immediate output is activated/deactivated
Additional drying Indicates whether additional drying is activated/deactivated
Graphic logs Indicates whether the graphic log recording is activated/deactivated
Energy-saving
mode
Indicates whether the steam sterilizer is currently in energy-saving
mode
Service area Indicates whether a service technician is logged-in to the service area
CF card status Indicates whether a CF card has been inserted and whether a reading
or writing action is in process
