5 First steps
17
5 First steps
Setup and installation
PLEASE NOTE
Comply with the specifications of the technical manual during set-up and installation.
This contains all building-side requirements.
Record of installation and setting up
The record of installation and setting up is to be completed by the responsible stockist and a copy sent to
MELAG as proof of the correct set-up, installation and initial commissioning. This is a constituent part of
any guarantee claim.
Feed water supply
Steam sterilizer requires the use of distilled or demineralized water, known as feed water. Annex C of
EN13060 specifies the guideline values to be observed.
The steam sterilizer requires c. 3 l feed water for the first filling of the steam generator.
The feed water supply is effected either via the internal feed water tank or via a separate water treatment
unit (e.g. MELAdem40 / MELAdem47). The used feed water, so called waste water is either collected in
the internal storage tank on the waste water side (left) and emptied manually or disposed of automatically
via a building-side waste water connection.
NOTICE
When connecting an external feed water supply it is necessary to connect an external
wastewater outflow as well.
There is a risk that hot wastewater might run through the emergency overflow.
Using the internal water storage tank
Video tutorial
See also "Filling and emptying stand-alone autoclaves".
The internal storage tank holds max. 5 litres. This volume of feed water is sufficient for up to 7 sterilization
runs.
1. To fill the storage tank with fresh feed water remove
the lid and fill the right-hand chamber of the storage
tank with fresh feed water up to the MAX mark.
2. Set the feed water supply in the display
toINTERNAL, see settings, Water supply
[}page55].
