QDR InfiniBand Switch Platform User Manual Rev 3.4
Mellanox Technologies
45
------------
MST PCI module loaded
MST PCI configuration module loaded
MST devices:
------------
/dev/mst/mt26428_pciconf0 - PCI configuration cycles access.
bus:dev.fn=04:00.0 addr.reg=88 data.reg=92
Chip revision is: B0
/dev/mst/mt26428_pci_cr0 - PCI direct access.
bus:dev.fn=04:00.0 bar=0xca200000 size=0x100000
Chip revision is: B0
Inband devices:
-------------------
/dev/mst/CA_MT25418_eagle8_HCA-1_lid-0x0068
/dev/mst/SW_MT48438_IS5030-Ranana-2_lid-0x0001
/dev/mst/SW_MT48438_IS5030-Ranana_lid-0x0002
[root@eagle1 ~]# flint -d /dev/mst/SW_MT48438_IS5030-Ranana_lid-0x0002 -qq q
-W- Running quick query - Skipping full image integrity checks.
Image type: FS2
FW Version: 7.4.2200
Device ID: 48438
Description: Node Sys image
GUIDs: 0002c902004429e8 0002c902004429eb
Board ID: n/a (MT_0D00110012)
VSD: n/a
PSID: MT_0D00110012
Other tools like flint can also be useful.
4.3.2.1 Instructions for Reprogramming Over the InfiniBand Network
To update an InfiniScale IV switch device having a specific GUID (for example,
0x00000006660abcd0) or LID, the following are the recommended steps to update the device
firmware.
1. Make sure all subnet ports are in the active state. One way to check this is to run opensm, the
Subnet Manager.
[root@mymach]> /etc/init.d/opensmd start
opensm start [ OK ]
2. Make sure the local ports are active by running ‘ibv_devinfo’.
3. Obtain the device LID.
1. Use the “mst ib add” command:
The “mst ib add” runs the ibdiagnet/ibdiscover tool to discover the InfiniBand fabric and then lists the
discovered IB nodes as an mst device under /dev/mst/ directory. These devices can be used for access by
other MFT tools.
[root@mymach]> mst ib add
