Delivery, Transport and Setting Up
19 D30374 11/2023
4.6.1 Preconditions
ü The installation site must be flat and horizontal and must be able to reliably bear the
weight of the unit (see
}3.7Technical Data). Place the unit on a heat-resistant, fireproof and non-flammable
surface.
ü A 230 V or 115 V power connection must be available at the installation site,
depending on the version (see }3.6Nameplate).
ü The distance between the wall and the rear panel of the appliance must be at least
15cm.
ü The clearance from the ceiling must not be less than 20cm and the side clearance
from walls or nearby appliances must not be less than 5cm. Sufficient air circulation
in the vicinity of the appliance must be guaranteed at all times.
ü For appliances with castors or for appliances standing on sub frames with castors,
always position the castors in a forward direction and lock the castor brakes to ensure
that the appliances remain securely in place.
▶ Place the unit in the designated position as shown below.
See also
2 Technical Data [}14]
2 Nameplate [}13]
4.6.2 Anti-tilt bracket
Attach the appliance to a wall with the anti-tilt bracket. The anti-tilt bracket is included in
the scope of delivery.
1. Screw the anti-tilt bracket to the back of the appliance as illustrated.
i
Depending on the ambient conditions, the anti-tilt bracket can be fastened at one of the
two holes provided in the appliance.
