Delivery, Transport and Setting Up
20 D30374 11/2023
2. Bend the anti-tilt bracket up by 90° to achieve the required clearance from the wall
(observe the minimum clearance).
3. Find a suitable wall, drill a hole, insert a plug and screw on the anti-tilt bracket.
4.6.3 Adjusting the Doors
You can adjust the doors if necessary, for example if they are warped due to uneven
flooring. There are two adjusting screws on each door for this purpose; one at the top and
one at the bottom.
First, adjust the setting at the top of the door and, if this is not sufficient, adjust the
bottom.
i
A service video which explains how to adjust the door is available:
www.memmert.com/de/downloads/media/service-videos/
1. Open the door.
2. Loosen the screws.
3. Adjust the position of the door.
4. Tighten the screws again.
5. Check the position of the door.
6. Readjust if required.
