Maintenance and Care
ICN-V stabilization, right side Mobil 4x4 4x4 Plus 4x4 Plus
Sensor
1 Stabilizator right front - in x x x
2 Stabilizator right front - out x x x
3 Steered wheel right front - inwards x
Lift axle right front - up x
Steering wheel right - inwards x x
4 Steered wheel right front - outwards x x
Lift axle right front - down x
Steering wheel right - outwards x x
5 Steering wheel rear - inwards x
6 Steering wheel rear - outwards x
7 Communitation - pads-wheel steering x x x x
8 2. gage x x x x
9 Telescopic stabilizer right - out x x
Mountain stabilizer right - up x x
10 Telescopic stabilizer right - in x x
Mountain stabilizer right - down x x
11 Stabilizator right front - down x x x x
12 Stabilizator right front - up x x x x
13 Wheel rear right - down x x x x
14 Wheel rear right - up x x x x
15 Wheel rear right - outwards x x x x
16 Wheel rear right - inwards x x x x
CR2011 Option modul ID4
Rototilt Harvester Woody50 Felling-head Naarva Grip
1 Grab open Roller feed slow Guillotine Grab closed
2 Close Grab Roller open / closed Rotator left
3 Tilt left Close Grab Tilt up
4 Tilt right Open Grab Loading Grab closed
5 Open auxiliary Grab Roller feed forward Loading Grab open
6 Close auxiliary Grab Roller feed backwards Tilt down
7 Turn totator to left Turn rotator to left Rotator to right
8 Turn rotator to right Turn rotator to right Retaining Grab open
CR2011 Option modul ID5
1
2 Forestry feed unit up / down
3 Position forestry head / floating position
4 Forestry automatic felling position
5 Forestry gripper pressure reducer
6 Forestry saw
7 Fix forestry head / floating position
8 Forestry automatic mode on / off
