Page 60 www.menzimuck.com
Control and Display elements
Limit
Symbol blinks
Timed buzzer
Permanent buzzer
Can be acknowledged
Repeats after ....
Pre-heating Diesel engine
x
Diesel engine air intake filte
Alarm: Filter dirty x x x 60s
CAN Bus faulty (left image)
No connection between ECU-Engine / GLR/RC4-4/20 x
Engine oil pressure
Alarm: Pressure too low x x x 60s
Coolant level too low
Alarm: Level toot low x x x 60s
Hydraulic return filter
Alarm: Filter dirty x x x 60s
Central lubrication level (right image)
Alarm: Level too low x
Overpressure central lubrication (blinks)
Pressure in central lubrication to high
x
Maintenance due
Deletion only with maintance code ! x
CAN Bus faulty (right image)
No connection between joystick / chassis comand x x x 60s
Left-turn signal
Signal on x
Working headlights
Headlights on x
Right-turn signal
Signal on x
