Operation Manual Menzi Muck A91 Page 87
Control and Display elements
6.9.2 Filling chassis tank
1. Pull out lling hose from the running board
2. Remove plugs
1
2
3. Open the chassis tank cover.
Note !
Chassis tank cover
The chassis tank cover rotates freely when closed. Un-
lock the cover with the key
Attention !
Escaping fuel
• Can result in damage to property.
• Position the machine so that the chassis tank cover
is at the highest position.
3
4
4. Attach lling hose to the chassis tank.
5. Set switchover cock to horizontal position.
6. Refuel as described above.
7. Make a visual check of the lling level of the chassis tank at the
lling nozzle.
7
5
