Control and Display elements
6.9.3 Transferring fuel to chassis tank
1. Position upper vehicle section so that the chassis tank can be
reached with the suction hose.
2. Unscrew the cover from the suction hose.
3. Unlock the chassis tank cover and open the tank cover. If the
chassis tank cover rotates freely then it is closed.
2
3
Note !
Chassis tank cover
The chassis tank cover rotates freely when closed. Un-
lock the cover with the key.
Attention !
Escaping fuel
• Can result in damage to property.
• Position the machine so that the chassis tank cover
is at the highest position.
5. Set switchover cock to vertical position.
6. Refuel as described above.
4
4. Insert suction hose in chassis tank.
5
6
