MAINTENANCE
116
6. Flo-Torq II Drive Hub Propellers - Install forward thrust hub,
replaceable drive sleeve, propeller, thrust hub, propeller nut
retainer and propeller nut onto the shaft.
b
c
a
d
f
e
ob00421
a - Propeller nut
b - Propeller nut retainer
c - Thrust hub
d - Propeller
e - Replaceable drive
sleeve
f - Forward thrust hub
7. Place a block of wood between gearcase and propeller and
torque to specifications.
Description Nm lb. in. lb. ft.
Propeller nut 75 55
8. Secure propeller nut by bending three of the tabs into the
thrust hub grooves.
ob00422
Spark Plug Inspection and Replacement
1. Remove top and rear cowlings. Refer to Cowl Removal and
Installation.
2. Disconnect the six wiring harness connectors from pencil coil
connections.

Table of Contents

Other manuals for Mercury 200 VERADO

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercury 200 VERADO and is the answer not in the manual?

Mercury 200 VERADO Specifications

General IconGeneral
Engine Type4-Stroke
Gear Ratio1.85:1
Full Throttle RPM Range5800-6400 RPM
Fuel SystemElectronic Fuel Injection (EFI)
ExhaustThrough Prop
Horsepower200 HP
Fuel Induction SystemElectronic Fuel Injection (EFI)
Shaft Length20", 25"
StartingElectric
Fuel Type87 Octane
Cylinder ConfigurationInline-6
Cooling SystemWater-cooled with thermostat
